| Print Specifications |
|
| Print Method |
24-pin impact dot matrix |
| Print Speed (10 cpi) |
Ultra High Speed Draft: Up to 540 cps High Speed Draft: 480 cps Letter Quality (LQ): 120 cps |
| Print Direction |
Bidirectional with logic seeking |
| Printhead Life |
400 million strokes per wire |
| Reliability (MTBF) |
30,000–35,000 Power-On Hours (POH) |
| Copies |
One original + up to 6 carbon copies |
| Paper Handling |
|
| Passbook Thickness |
Up to 2.6 mm |
| Cut Sheet Paper |
Width: 65–243 mm Length: 67–297 mm |
| Multi-Part Forms |
Thickness: 0.12–0.53 mm |
| Paper Path |
Front-in, front-out OR front-in, rear-out (manual insertion) |
| Smart Functionality |
Automatic sheet alignment, automatic platen gap adjustment |
| Connectivity & Compatibility |
|
| Interfaces |
Bi-directional parallel (IEEE-1284), Serial, USB 2.0 (High-speed) |
| Emulations |
PR2, WNI4915, IBM4722, IBM PPDS, ESC/P2 |
| Supported OS |
Microsoft Windows (including Windows 10 & Windows Server) |
| General Specifications |
|
| Dimensions (W × D × H) |
384 × 280 × 203 mm |
| Weight |
7.8 kg |
| Noise Level |
52 dB(A) (for passbook printing) |
| Power Consumption |
Operation: 61 W Sleep: 0.7 W |
| Ribbon |
Long-life black fabric ribbon (compatible across Epson passbook printer range) |
