| Model |
CS-H9c-R105-8H55WFL4GA |
| Image Sensor |
1/3” Progressive Scan CMOS |
| Shutter Speed |
Self-adaptive shutter |
| Lens (Top) |
2.8mm @ F1.6 – Diagonal 110°, Horizontal 96°, Vertical 54° |
| Lens (Bottom) |
6mm @ F1.6 – Diagonal 60°, Horizontal 52°, Vertical 28° |
| PT Angle (Top Lens) |
Pan: 0~240° (Manual), Tilt: 15° fixed preset |
| PT Angle (Bottom Lens) |
Pan: 350°, Tilt: 80° |
| Minimum Illumination |
0.5 Lux @(F1.6, AGC ON), 0 Lux with IR |
| Lens Mount |
M12 |
| Day & Night |
IR-cut filter with auto switch |
| DNR |
3D DNR |
| WDR |
Digital WDR |
| Color Night Vision |
Up to 40 m |
| Black & White Night Vision |
Up to 30 m (98 ft) |
| Max Resolution |
3K (2880 × 1620) |
| Frame Rate |
Self-adaptive |
| Video Compression |
H.265 / H.264 |
| H.265 Type |
Main Profile |
| Video Bit Rate |
Ultra-HD / Full HD / Standard / Adaptive |
| Audio Bit Rate |
Self-adaptive |
| Wi-Fi Standards |
IEEE 802.11 a/b/g/n/ac/ax |
| Frequency Range |
2.4 GHz & 5 GHz bands |
| Channel Bandwidth |
20MHz (2.4G), 20/40/80MHz (5G) |
| Wireless Security |
WPA-PSK / WPA2-PSK |
| Max Transmission Rate |
Up to 600 Mbps (Wi-Fi 6) |
| Protocol |
EZVIZ Cloud Proprietary Protocol |
| Wired Network |
RJ45 × 1 (10M / 100M Adaptive) |
| 4G LTE Bands (EU) |
B1/B3/B5/B7/B8/B20/B28 |
| 4G LTE Bands (LA) |
B2/B3/B4/B5/B7/B8/B28/B66 |
| Smart Alarm |
AI Human & Vehicle Detection, Motion Detection |
| PT Function |
Auto tracking, preset points, patrol mode |
| Customized Alert Area |
Supported |
| Two-Way Talk |
Supported |
| Preset Locations |
Supported |
| General Functions |
Anti-Flicker, Dual-Stream, Heartbeat, Password Protection, Watermark |
| Local Storage |
microSD card up to 512 GB |
| Cloud Storage |
EZVIZ CloudPlay (Subscription required) |
| Operating Conditions |
-30°C to 50°C, ≤95% humidity (non-condensing) |
| IP Grade |
Weatherproof design |
| Power Supply |
DC 12V / 1.5A |
| Power Consumption |
Max. 18W |
| Dimensions |
147 × 116 × 142 mm |
| Package Dimensions |
150 × 150 × 194 mm |
| Net Weight |
627.3 g |
| Weight with Package |
970.4 g |
| In the Box |
Camera, Drilling Template, Screw Kit, Waterproof Kit, Power Adapter, Regulatory Info, Quick Start Guide |
| Certifications |
CE / UL / WEEE / RoHS / REACH |
