| Brands Available |
Gigabyte, ASRock, ASUS, ECS ,TG (random available) |
| CPU Support |
Intel® Socket 1150 for 4th Gen Core™ i7/i5/i3, Pentium®, Celeron® (22nm CPUs)Intel® Turbo Boost Tech 2.0 |
| Chipset |
Intel® H81 |
| Memory |
2 x DIMM, Max 16GB DDR3 1600/1333/1066 MHzDual ChannelSupports Intel® XMP |
| Graphics |
Integrated Graphics ProcessorOutputs: DVI-D & RGBMax Res: 1920×1200 @ 60HzShared Memory: 1024MB |
| Expansion Slots |
1 x PCIe 2.0 x162 x PCIe 2.0 x11 x PCI |
| Storage |
2 x SATA 6Gb/s (yellow)2 x SATA 3Gb/s (dark brown)Supports Intel® Rapid Start & Smart Connect Tech |
| LAN |
Realtek® RTL8111G Gigabit LAN |
| Audio |
Realtek® ALC887-VD 8-Channel HD Audio CODECJack detection, Multi-streaming, Anti-pop, Front panel retasking |
| USB Ports |
2 x USB 3.1 Gen 1 (rear, blue)8 x USB 2.0 (4 rear, 4 mid-board) |
| OS Support |
Windows 10, Windows® 8, Windows® 7 |
| Back I/O Ports |
1 x PS/2 Keyboard1 x PS/2 Mouse1 x DVI-D1 x D-Sub1 x LAN (RJ45)2 x USB 3.14 x USB 2.01 x Parallel1 x Audio Jack |
| Internal I/O Ports |
2 x USB 2.0 headers (support 4 USB 2.0 ports)1 x TPM header1 x COM header2 x SATA 6Gb/s2 x SATA 3Gb/s1 x CPU Fan1 x Chassis Fan1 x 24-pin EATX1 x 4-pin ATX 12V1 x Front panel audio1 x Internal speaker1 x System panel1 x Clear CMOS jumper |
